Pro-Shield™ Durable Power Sports Laminate

Resists Failure In Abusive Applications. Thick. Tough. Durable.
  • High-Gloss, and now available in Matte.
  • More durable and rigid than Convex laminate.
  • Conforms with the aid of a heat gun.

Professionals need crystal clear, thick, heavy duty, abrasion resistant laminates. We developed Pro-Shield as the  durable power sports laminate solution for shrouds and other areas on MX bikes that receive the highest amount of abrasion from boots and knee braces. Most professional shops choose the combination of Convex® High-Bond with Pro-Shield laminate because even though Pro-Shield is harder and less conformable, you can mold Pro-Shield to most shapes with the aid of a heat gun. Pro-Shield comes in 7 and 12 mil thicknesses, and we have recently released 7 mil matte.

ps_promo

Overview

Pro-Shield™ is the solution for plastics on MX bikes that receive a tremendous amount of abrasion from boots & knee braces. Many professional shops choose to use the combination of Convex® High-Bond with Pro-Shield durable power sports laminte for the whole bike, because they can mold the Pro-Shield to almost any shape with the aid of a heat gun. Pro-Shield comes in 7 and 12 mil. That means that when you print with 6 mil Convex®, and use Pro-Shield 12 mil, your result is a 19.5 mil thick decal (there is 1.5 mils of psa on the 12 mil vinyl).  This provides an extremely durable barrier for your graphics.

Pro-Shield_300x156

Specifications

General Description: Flexible heavy duty clear vinyl with clear permanent acrylic adhesive. Different combinations of base materials and Pro-Shield can be used to achieve a variety of decal thicknesses and prices.

Thickness, 7 & 12 mil 5.5 mil vinyl with 1.5 mil of adhesive, 12 mil vinyl with 1.5 mil of adhesive
Outdoor Life 2 years
Shelf Life 1 year stored at 70º F & 50%RH
Adhesive Properties High Performance permanent acrylic pressure sensitive adhesive works on most surfaces.
Service Temperature Range -40º F to 176º F
Minimum Application Temp. 50º F

Recommended Application Techniques: Convex® brand base materials are recommended in combination with Pro-Shield. Apply with cold laminator or by hand. When laminate is separated from the liner it can stretch during the laminating process. Take care not to apply too much reverse tension on the supply roll.  If you do, it will stretch the laminate and curl up immediately after it is cut.

All of the descriptive information listed above is our recommendation only. This information does not suggest or constitute a written or verbal warranty or guaranty of any kind by the manufacturer or distributor of this product. Purchasers of this product shall be responsible for independently determining the suitability of the material for the intended application.  GMS0414 GRAPHIC MARKING SYSTEMS

For Solvent, Latex, and UV ink jets

Pro-Shield 12 mil, 7 mil and 7 mil matte laminate for wide format ink jets

Thickness

Width

Length

Color

Part Number

12 mil

20 inches

10 yards

Clear

PS122010C

12 mil

20 inches

50 yards

Clear

PS122050C

12 mil

24 inches

10 yards

Clear

PS122410C

12 mil

24 inches

50 yards

Clear

PS122450C

12 mil

27 inches

10 yards

Clear

PS122710C

12 mil

27 inches

50 yards

Clear

PS122750C

12 mil

30 inches

10 yards

Clear

PS123010C

12 mil

30 inches

25 yards

Clear

PS123025C

12 mil

30 inches

50 yards

Clear

PS123050C

12 mil

48 inches

50 yards

Clear

PS124850C

12 mil

54 inches

25 yards

Clear

PS125425C

12 mil

54 inches

50 yards

Clear

PS125450C

Thickness

Width

Length

Color

Part Number

7 mil

20 inches

10 yards

Clear

PS72010C

7 mil

20 inches

50 yards

Clear

PS72050C

7 mil

24 inches

10 yards

Clear

PS72410C

7 mil

24 inches

50 yards

Clear

PS72450C

7 mil

27 inches

10 yards

Clear

PS72710C

7 mil

27 inches

50 yards

Clear

PS72750C

7 mil

48 inches

50 yards

Clear

PS74850C

7 mil

54 inches

50 yards

Clear

PS75450C

7 mil Matte

27 inches

10 yards

Clear

PS72710CM

7 mil Matte

27 inches

50 yards

Clear

PS72750CM

7 mil.Matte

54 inches

50 yards

Clear

PS75450CM

Custom sizes, 5 yd rolls for samples, and Combo Kits are available.

All of the descriptive information listed above is our recommendation only. This information does not suggest or constitute a written or verbal warranty or guaranty of any kind by the manufacturer or distributor of this product. Purchasers of this product shall be responsible for independently determining the suitability of the material for the intended application. GMS0314

Thermal Printers

Pro-Shield Laminate For Gerber Edge, Edge II & Edge FX

Thickness

Width

Length

Color

Part number

12 mil

13 inches

10 yards

Clear

PS121310C

12 mil

13 inches

25 yards

Clear

PS121325C

12 mil

13 inches

50 yards

Clear

PS121350C

7 mil

13 inches

10 yards

Clear

PS71310C

7 mil

13 inches

50 yards

Clear

PS71350C

7 mil Matte

13 inches

10 yards

Clear

PS71310CM

7 mil Matte

13 inches

50 yards

Clear

PS71350CM

 Custom sizes, 5 yd rolls for samples, and Combo Kits are available.

GSP Software Settings:  For Pro-Shield laminates, use double cuts. You should perform test cuts to determine the exact cutter settings for the the material.  Use a 45º or 60º BLADE on any combination of material 8 mil or thicker.

PS7Matte-Gloss

Did you know that you can print on Pro-Shield and Pro-Form after you laminate?  Our laminates are designed for laminating as well as printing.  This is a sample of the front panel under the headlights on a  Polaris RMK sled.  We added some ghosted design elements in the form of a matte finish on top of the laminate.  It all looks black until you get close enough in the right light to see the scroll work in matte.  The darker areas in the picture are the gloss areas.  In the printing industry, this is known as a spot varnish.  This is a unique capability of the Gerber Edge®.  Want to know more?  E-mail us at Specialist@Graphicms.com.

All of the descriptive information listed above is our recommendation only. This information does not suggest or constitute a written or verbal warranty or guaranty of any kind by the manufacturer or distributor of this product. Purchasers of this product shall be responsible for independently determining the suitability of the material for the intended application. GMS0414

Recommended Base Media

CHB_200x107

Convex High-Bond is used to make decals for motocross bikes and other applications for low-energy plastic surfaces.

Finish: Gloss or Matte for Gerber and Summa thermal printers.  High-Bond Matte is recommended for ink jets.

Applications: Use Convex when you need an extremely pliable vinyl to cover complex curves.  Convex was originally designed for helmets with GearWrap adhesive.  Convex with High-Bond adhesive is designed for low-energy plastics.

MW-Logo

Motowrap: gives you excellent high-bond adhesion to plastics, and will stay on even in frigid weather.

Finish: Gloss for the Gerber Edge and Ink Jets

Applications:   MotoWrap is great for Sleds and other machines that will feel the cold.  It will conform to the complex curves of MX bikes and ATV fenders.  It is also compatible with MotoWrap, Pro-Form, and Pro-Shield laminates.  MotoWrap™ gives you the best mix of economy, adhesion and conformability to compete in the fast-paced decal market.

PitbullMX-237x110

Pitbull™ is the vinyl with adhesive that won’t let go.

Finish: Gloss for thermal printers and inkjets.

Applications: Pitbull is ideal for LSE applications such as pelican cases and motorsport vehicles.  It also works on coolers and other textured plastic surfaces.  Due to the aggressiveness of the adhesive, wet application techniques may be preferred.  Pitbull vinyl may not remove cleanly from surfaces.  For that reason, on MX plastics it may be advantageous to sell new plastic with the decals already installed.
